Pump Kits
Jergens Pump Kits include the valves and subplates needed to actuate StayLock Clamps. They are only available for the Shoebox™ model Air-Powered Hydraulic Pump.
Pump Kit (Part No. 61757) includes:
-
36:1 Boost Ratio Shoebox™ Air Powered Hydraulic Pump (Part No. 61755)
-
4-Way Zero-Leakage Valve (Part No. 61642)
-
D03 Subplate for Shoebox™ Pump (Part No. 61647)
-
6000 psi. Hydraulic Gauge (Part No. 60703)
-
Note: The valve, subplate, and gauge are supplied mounted on the pump.
Pump Kit (Part No. 61758) includes:
-
71:1 Boost Ratio Shoebox™ Air Powered Hydraulic Pump (Part No. 61756)
-
4-Way Zero-Leakage Valve (Part No. 61642)
-
D03 Subplate for Shoebox™ Pump (Part No. 61647)
-
10,000 psi. Hydraulic Gauge (Part No. 60706)
-
Note: The valve, subplate, and gauge are supplied mounted on the pump.
Documents
Pump Kits
Select a part number for CAD drawings, price and stock availability.
| Part Number | CAD | Unit | Items Included |
|---|---|---|---|
| 61757 | Inch | 61755, 61642, 61647, 60703 | |
| 61758 | Inch | 61756, 61642, 61647, 60706 | |
| 61759 | Inch | 61755, 61643, 60703 |
