Plastic Locking Wing Knobs
Jergens Plastic Locking Wing Knobs have a wing-shaped head with varying execution, designed to allow high tightening torque values.
Features, Benefits, & Product Specifications:
-
Material: Glass-Fibre Reinforced Polyamide-Based (PA) Technopolymer
-
Finish: Black Matte
-
Insert: Brass Insert with Tapped Blind Hole
-
Resistant to solvents, oils, greases, and other chemical agents
Plastic Locking Wing Knobs
Select a part number for CAD drawings, price and stock availability.
| Part Number | CAD | Unit | A (In) | B (In) | C (In) | D | E (In) |
|---|---|---|---|---|---|---|---|
| 33776 |
|
Metric | 26 | 13 | 11 | M5 | 5 |
| 33777 |
|
Metric | 32 | 15 | 13 | M6 | 8 |
| 33778 |
|
Metric | 40 | 17 | 15.5 | M8 | 8 |
