Plastic Locking Wing Knob with Stud by ELESA®
Jergens Plastic Locking Wing Knob with Stud by ELESA® has a wing-shaped head with varying execution, designed to allow high tightening torque values.
Features, Benefits, & Product Specifications:
-
Material: Glass-Fibre Reinforced Polyamide Based (PA) Technopolymer
-
Finish: Black Matte
-
Stud: Zinc-Plated Steel Stud with Chamfered Flat End
-
Resistant to solvents, oils, greases, and other chemical agents
Plastic Locking Wing Knob with Stud by ELESA®
Select a part number for CAD drawings, price and stock availability.
| Part Number | CAD | Unit | A (In) | B (In) | C (In) | D | E (In) |
|---|---|---|---|---|---|---|---|
| 33765 |
|
Inch | 1.02 | 0.51 | 0.43 | 10-32 | 0.500 |
| 33767 |
|
Inch | 1.26 | 0.59 | 0.51 | 1/4-20 | 0.500 |
| 33768 |
|
Inch | 1.26 | 0.59 | 0.51 | 1/4-20 | 0.750 |
| 33769 |
|
Inch | 1.26 | 0.59 | 0.51 | 1/4-20 | 1.000 |
| 33770 |
|
Inch | 1.57 | 0.67 | 0.61 | 5/16-18 | 0.750 |
| 33771 |
|
Inch | 1.57 | 0.67 | 0.61 | 5/16-18 | 1.000 |
| Part Number | CAD | Unit | A (mm) | B (mm) | C (mm) | D | E (mm) |
|---|---|---|---|---|---|---|---|
| 33781 |
|
Metric | 26 | 13 | 11 | M5 | 16 |
| 33782 |
|
Metric | 32 | 15 | 13 | M6 | 16 |
| 33783 |
|
Metric | 32 | 15 | 13 | M8 | 16 |
| 33784 |
|
Metric | 40 | 17 | 15.5 | M8 | 25 |
| 33785 |
|
Metric | 40 | 17 | 15.5 | M10 | 30 |
