Miniature Insert Keylocking
Jergens Miniature Insert Keylocking are used to quickly repair stripped, damaged, or worn-out threads. They are also used in original equipment where they strengthen threads in soft metals like magnesium or aluminum. Our threaded inserts are easy to install and remove. No specialty drills, taps, or pre-winder tools are required. The keys are driven down into the threads of the surrounding base material, locking the insert in place.
Features, Benefits, & Product Specifications:
-
Insert Material & Finish: 303 Stainless Steel, Passivated
-
Key Material & Finish: 302 Stainless Steel, Passivated
-
Tolerances: ±0.010 for Inch, ±0.25mm for Metric
-
Internal Threads:
-
Inch: Per Fed Std H28/21, MJ Form
-
Metric: Per SAE AS8879
-
-
Furnished with (2) locking keys
-
Material Identification Mark: None
-
Lubrication: Dry Film Lube on Self-Locking Inserts only
-
Special materials, sizes, and Mil-Spec available upon request
-
RoHS compliant
Note(s):
-
Part No.'s 26286 & 27286 have a modified minor diameter.
-
High-Strength Materials Available: These miniature inserts are also manufactured in high-strength stainless steel (A-286 with heat treatment) and alloy steel (4140 with heat treatment).
Miniature Insert Keylocking
Select a part number for CAD drawings, price and stock availability.
| Part Number | CAD | Unit | Internal Thread 3B | External Thread 2A | Thread Length G (In) | Length H (In) | Installation Tool Part Number | Style |
|---|---|---|---|---|---|---|---|---|
| 26283 | Inch | 2-56 | 8-32 | 0.090 | 0.120 | 22552 | Non-Locking | |
| 26284 | Inch | 4-40 | 10-32 | 0.125 | 0.170 | - | Non-Locking | |
| 26285 | Inch | 6-32 | 12-28 | 0.125 | 0.170 | 22556 | Non-Locking | |
| 26286 | Inch | 8-32 | 1/4-28 | 0.175 | 0.220 | 22558 | Non-Locking | |
| 27283 | Inch | 2-56 | 8-32 | 0.090 | 0.120 | 22552 | Self-Locking | |
| 27284 | Inch | 4-40 | 10-32 | 0.125 | 0.170 | - | Self-Locking | |
| 27285 | Inch | 6-32 | 12-28 | 0.125 | 0.170 | 22556 | Self-Locking | |
| 27286 | Inch | 8-32 | 1/4-28 | 0.175 | 0.220 | 22558 | Self-Locking |
| Part Number | CAD | Unit | Internal Thread (4H6H) | External Thread 4h | Thread Length G (mm) | Length H (mm) | Installation Tool Part Number | Style |
|---|---|---|---|---|---|---|---|---|
| 26382 | Metric | M2 X 0.4 | M4 X 0.7 | 2.20 | 3.0 | 22682 | Non-Locking | |
| 26383 | Metric | M2.5 X 0.45 | M4.5 X 0.75 | 2.70 | 3.81 | 22683 | Non-Locking | |
| 26384 | Metric | M3 X 0.5 | M5 X 0.8 | 3.10 | 4.25 | 22684 | Non-Locking | |
| 26386 | Metric | M4 X 0.7 | M6 X 0.75 | 4.11 | 5.25 | 22686 | Non-Locking | |
| 27382 | Metric | M2 X 0.4 | M4 X 0.7 | 2.20 | 3.0 | 22682 | Self-Locking | |
| 27383 | Metric | M2.5 X 0.45 | M4.5 X 0.75 | 2.70 | 3.81 | 22683 | Self-Locking | |
| 27384 | Metric | M3 X 0.5 | M5 X 0.8 | 3.10 | 4.25 | 22684 | Self-Locking | |
| 27386 | Metric | M4 X 0.7 | M6 X 0.75 | 4.11 | 5.25 | 22686 | Self-Locking |
