Hydraulic Pre-Fill Boosters Kit
Jergens Hydraulic Pre-Fill Boosters Kit provides a complete compact power source for our Hydraulic Production Vises. This air-operated booster provides enough hydraulic volume to power up to (6) Jergens Hydraulic Production Vises.
Features, Benefits, & Product Specifications:
-
Self bleeding
-
Easy view reservoir
-
30:1 boost ratios
Each Hydraulic Pre-Fill Boosters Kit includes:
-
(1) Jergens 30:1 Self-Bleeding Pre-Fill Booster (Part No. 61705)
-
(1) Filter Regulator
-
(1) 4-Way Push Button Actuator Valve
-
Comes plumbed with all fittings & hoses
Documents
Hydraulic Pre-Fill Boosters Kit
Select a part number for CAD drawings, price and stock availability.
| Part Number | CAD | Unit | Reservoir Capacity (cu. in.) | High Pressure Volume (cu. in.) | Minimum Input (psi) | Maximum Input (psi) | Boost Ratio | Maximum Output (psi) | Weight (lbs) |
|---|---|---|---|---|---|---|---|---|---|
| 61725 |
|
Inch | 50 | 3 3/4 | 40 | 125 | 30:1 | 3,750 | 28 |
| Part Number | CAD | Unit | Reservoir Capacity (Liters) | High Pressure Volume (cu. cm) | Minimum Input (bar) | Maximum Input (bar) | Boost Ratio | Maximum Output (bar) | Weight (kgs) |
|---|---|---|---|---|---|---|---|---|---|
| 61725 |
|
Metric | 0.8 | 61 | 2.7 | 8.6 | 30:1 | 258.5 | 13 |
