HDC2600 Heavy Duty Cam Swing Clamps
Jergens Magna Force Heavy Duty Cam Clamps are a unique, patented range of manually operated cam clamps with advantages over hydraulic automated clamping systems. Each model features a patented rugged build quality ideal for machine shops. They offer significant cost benefits over strap clamps in repetitive machining and are a fraction of the cost of hydraulic system clamping.
Features, Benefits, & Product Specifications:
- Operating Clamping Forces:
- 1,350 lbs (Hand Applied)
- 2,700 lbs (Mallet Applied)
- Weight: 2.0 lbs
- Supplied complete with set screw & nuts
Note(s):
-
⚠ WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Documents
HDC2600 Heavy Duty Cam Swing Clamps
Select a part number for CAD drawings, price and stock availability.
| Part Number | CAD | Unit | Model Number | Rotation | Operating Clamping Force - Hand (lbs) | Operating Clamping Force - Mallet (lbs) | Weight (lbs) |
|---|---|---|---|---|---|---|---|
| 72409 |
|
Inch | HDC2600S | Clockwise | 1,350 | 2,700 | 2 |
| 72410 |
|
Inch | HDC2600SB | Counter Clockwise | 1,350 | 2,700 | 2 |
