HDC1800 Heavy Duty Cam Swing Clamps

Jergens Magna Force Heavy Duty Cam Clamps are a unique, patented range of manually operated cam clamps with advantages over hydraulic automated clamping systems. Each model features a patented rugged build quality ideal for machine shops. They offer significant cost benefits over strap clamps in repetitive machining and are a fraction of the cost of hydraulic system clamping.

Features, Benefits, & Product Specifications:
  • Operating Clamping Forces:
    • 1,120 lbs (Hand Applied)
    • 1,800 lbs (Mallet Applied)
  • Weight: 0.9 lbs
  • Supplied complete with set screw & nuts
Note(s):

Documents

HDC1800 Heavy Duty Cam Swing Clamps

HDC1800 Heavy Duty Cam Swing Clamps
  • HDC1800 Heavy Duty Cam Swing Clamps
  • Line Art 72407 SWING , CLOCKWISE, 1800

Select a part number for CAD drawings, price and stock availability.

Part Number CAD Unit Model Number Rotation Operating Clamping Force - Hand (lbs) Operating Clamping Force - Mallet (lbs) Weight (lbs)
72407 icon_cad Inch HDC1800S Clockwise 1,124 1,800 0.9
72408 icon_cad Inch HDC1800SB Counter Clockwise 1,124 1,800 0.9
