HDC10000 Heavy Duty Cam Clamps

Jergens Magna Force Heavy Duty Cam Clamps are a unique, patented range of manually operated cam clamps with advantages over hydraulic automated clamping systems. Each model features a patented rugged build quality ideal for machine shops. They offer significant cost benefits over strap clamps in repetitive machining and are a fraction of the cost of hydraulic system clamping.

Features, Benefits, & Product Specifications:
  • Operating Clamping Forces:
    • 1,900 lbs (Hand Applied)
    • 11,240 lbs (Mallet Applied)
  • Weight: 2.9 lbs


HDC10000 Heavy Duty Cam Clamps

Select a part number for CAD drawings, price and stock availability.

Part Number CAD Unit Model Number Rotation Operating Clamping Force - Hand (lbs) Operating Clamping Force - Mallet (lbs) Weight (lbs)
72403 Inch HDC11000R Clockwise 1,910 11,240 2.9
72404 Inch HDC11000RB Counter Clockwise 1,910 11,240 2.9
