Haas® Pre-Engineered Ball Lock® Fixture Kits

Haas® Pre-Engineered Ball Lock® Fixture Kits are designed for Haas® Model No.'s MINI-MILL, VF-E, VF-0, VF-1, VF-OE, VF-2, VF-3, VF-4, & VF-5. Please use the "Jergens Ball Lock Mounting System_Ball Lock Fixtures Kits For HAAS_Catalog" for additional kit selection assistance.

Haas® Pre-Engineered Ball Lock® Fixture Kits include:
  • (1) Steel Subplate
  • Aluminum Fixture Plate(s)
  • Ball Lock® Shanks
  • T-Slot Nuts for mounting the subplate to the machine table
  • Sine Fixture Keys for accurate subplate locating
  • Socket Head Cap Screws





Documents

Haas® Pre-Engineered Ball Lock® Fixture Kits

Cardboard Box with the Jergens logo - placeholder for part number 50000
  • Cardboard Box with the Jergens logo - placeholder for part number 50000
  • Line Art 50000 HAAS KIT, 16X12, USE 49160 SUB

Select a part number for CAD drawings, price and stock availability.

Part Number CAD Unit Sub Plate Part Number Subplate (Qty. 1) Dimension (in) Fixture Plate Part Number Fixture Plate Size (in) Quantity: Std Fixture Plate(s) Ball Lock Shank Part Number Quantity: Std Ball Lock® Shanks Quantity: T-Slot Nuts (43306) Quantity: Sine Fixture Keys (39503) Quantity: Socket Head Cap Screws (1/2-13x15") Kit Weight (lbs)
50000 Inch 49160 16 x 12 28711 11 7/8 x 14 x 0.75 1 49601 4 4 2 4 77
50001 Inch 49161 28.75 x 12 28750 28.75 x 12 x 0.75 1 49601 4 6 2 6 138
50002 Inch 49162 26 x 14 28711 11 7/8 x 14 x 0.75 2 49601 8 6 2 6 146
50003 Inch 49163 26 x 16 28711 11 7/8 x 14 x 0.75 2 49601 8 6 2 6 162
50004 Inch 49164 26 x 16 28706 10 x 16 x 0.75 (Jigsaw) 2 49601 6 6 2 6 155
50005 Inch 49165 36 x 14 28713 14 x 14 x 0.75 2 49601 8 8 2 8 195
50006 Inch 49166 36 x 14 28706 10 x 16 x 0.75 (Jigsaw) 3 49601 9 8 2 8 194
50007 Inch 49167 36 x 16 28713 14 x 14 x 0.75 2 49601 8 8 2 8 218
50008 Inch 49168 36 x 16 28706 10 x 16 x 0.75 (Jigsaw) 3 49601 9 8 2 8 217
50009 Inch 49169 48 x 18 28717 16 x 16 x 0.75 2 49601 8 14 2 14 350
50010 Inch 49170 48 x 18 28711 11 7/8 x 14 x 0.75 2 49601 12 14 2 14 354
50011 Inch 49171 48 x 18 28706 10 x 16 x 0.75 (Jigsaw) 5 49601 15 14 2 14 362
50012 Inch 49172 48 x 20 28727 20 x 20 x 1 2 49612 8 14 2 14 426
50013 Inch 49173 48 x 20 28727 20 x 20 x 1 2 49612 8 14 2 14 426
50014 Inch 49174 48 x 20 28713 14 x 14 x 0.75 2 49601 8 14 2 14 376
50015 Inch 49175 48 x 20 28717 20 x 20 x 1 2 49601 8 14 2 14 384
50016 Inch 49176 48 x 20 28706 10 x 16 x 0.75 (Jigsaw) 5 49601 15 14 2 14 396
50017 Inch 49177 52 x 18 28715 16 x 16 x 0.75 3 49601 12 14 2 14 395
50018 Inch 49178 52 x 18 28711 11 7/8 x 14 x 0.75 4 49601 16 14 2 14 391
50019 Inch 49179 52 x 18 28706 10 x 16 x 0.75 (Jigsaw) 6 49601 18 12 2 12 398
50020 Inch 49180 52 x 20 28727 20 x 20 x 1 2 49612 8 14 2 14 454
50021 Inch 49181 52 x 20 28745 20 x 22 x 1 2 49612 8 14 2 14 460
50022 Inch 49182 52 x 20 28727 20 x 20 x 1 2 49612 8 14 2 14 454
50024 Inch 49184 52 x 20 28715 16 x 16 x 0.75 3 49601 12 14 2 14 432
50025 Inch 49185 52 x 20 28715 16 x 16 x 0.75 3 49601 12 14 2 14 432
50026 Inch 49186 52 x 20 28706 10 x 16 x 0.75 (Jigsaw) 6 49601 18 12 2 12 434
50027 Inch 49187 52 x 20 28706 10 x 16 x 0.75 (Jigsaw) 6 49601 18 12 2 12 434
50028 Inch 49188 52 x 23 28713 14 x 14 x 0.75 1 49601 8 14 2 14 515
50029 Inch 49189 52 x 23 28745 20 x 22 x 1 2 49612 8 14 2 14 515
50030 Inch 49190 52 x 23 28715 16 x 16 x 0.75 3 49601 12 14 2 14 487
50031 Inch 49191 52 x 23 28706 10 x 16 x 0.75 (Jigsaw) 6 49601 18 14 2 14 490
50032 Inch 49192 52 x 26 28746 25 x 26 x 1 2 49612 8 14 2 14 611
50033 Inch 49193 52 x 26 28746 25 x 26 x 1 2 49612 8 14 2 14 611
50035 Inch 49195 52 x 26 28715 16 x 16 x 0.75 3 49601 12 14 2 14 542
50036 Inch 49196 52 x 36 28706 10 x 16 x 0.75 (Jigsaw) 6 49601 18 14 2 14 545
