2,090 LB CAP Pull Action Latch Toggle Clamps with Additional Locking Mechanism

Jergens Pull Action Latch Toggle Clamps are designed for sealing chambers, doors, mold closures, or other applications requiring closure mechanisms. The handle can be moved to place the clamping U-Bolt or hook around the opposing latch and then pulled down to reach the locked position. The threaded hook or U-Bolt type bars offer an adjustment feature.

Features, Benefits, & Product Specifications:
  • Body Materials & Finishes:
    • Low Carbon Steel, Zinc Plated
    • 304 Stainless Steel
  • Handle: PVC Dipped
  • Holding capacity up to 2,090 lbs
  • Used for applications where a straight pulling action is required
  • Additional locking mechanism ensures that the clamp remains locked in any condition

Note(s):

2,090 LB CAP Pull Action Latch Toggle Clamps with Additional Locking Mechanism

Select a part number for CAD drawings, price and stock availability.

Part Number CAD Unit Drawing Movement (In) Holding Capacity (lbs) Weight (lbs)
70166 Inch 3.46 2,090 2.03
70166-SS Inch 3.46 2,090 2.03
Part Number CAD Unit Drawing Movement (mm) Holding Capacity (kN) Weight (kgs)
70166 Metric 88 9.30 0.92
70166-SS Metric 88 9.30 0.92
