Micro™ Machinable Fixture Clamps
These clamps, with the machinable steel washers, provide more flexibility for holding round or unusual shaped parts. Parts can be held directly to the fixture plate surface. A special screw is provided to hold the washer in the proper location during machining. The flat edge is in the same location as our Micro Clamps and are used where a higher clamping surface is required.
Micro™ Machinable Fixture Clamps
Select a part number for CAD drawings, price and stock availability.
| Part Number | CAD | Unit | A | B (In) | C (In) | D (In) | E (In) | F (In) | G (In) | H (In) | Torque (ft/lbs) | Maximum Holding Force (lbs) | Replacement Screw Part Number | Replacement Washer |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 68620 | Inch | 1/4-20 | 1/8 | 0.04 | 0.98 | 0.25 | 0.47 | 0.25 | 0.308 | 800 | 6.2 | 68975 | 68983 |
| Part Number | CAD | Unit | A | B | C (mm) | D (mm) | E (mm) | F (mm) | G (mm) | H (mm) | Torque (Nm) | Maximum Holding Force (N) | Replacement Screw Part Number | Replacement Washer |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 68624 |
|
Metric | M6 | 4M | 1.01 | 24.9 | 6.4 | 11.9 | 6.4 | 7.8 | 8.5 | 3358 | 68979 | 68983 |
| 68625 |
|
Metric | M10 | 7M | 1.52 | 31.2 | 8.9 | 18 | 7 | 10.2 | 28 | 8900 | 68980 | 68984 |
| 68626 |
|
Metric | M12 | 7M | 1.52 | 31.2 | 8.9 | 18 | 7 | 10.2 | 28 | 8900 | 68980 | 68984 |
| 68627 |
|
Metric | M16 | 12M | 2.54 | 43.9 | 14 | 28.6 | 8.9 | 15.0 | 135 | 26700 | 68982 | 68986 |
